Bilstein B14 part 47-281387 is listed for the vehicle variants in the application table below. Match your chassis, engine, factory suspension and axle ratings to the relevant row before ordering.
B14 uses threaded ride-height adjustment with vehicle-specific fixed damping. It suits drivers who want to choose the ride height without a damping-adjustment dial.
Application and lowering table
RENAULT CLIO IV (BH_)
0.9 TCe 75, 0.9 TCe 90, 0.9 TCe 90 LPG, 1.2 16V, .2 LPG 16V, 1.2 TCe 120, 1.5 dCi 75, 1.5 dCi 90, .5 dCi 110 11/12– 06/15 54–88 kW
- Front lowering: 30-40 mm
- Rear lowering: 30-40 mm
Fitment conditions and axle ratings: Type: ex. RS; Threaded Suspension (height adjustable); Lowering ca. [mm]: 30-40 mm FA: Axle load [kg] to 960 kg RA: Axle load [kg] to 893 kg
*Approximate lowering relative to the original suspension specified in the relevant row. Factory sports suspension, axle load and vehicle equipment can change the resulting drop. When several rows apply to the same model, their conditions distinguish the permitted configuration; do not select a range by model name alone.
Before ordering
- Check the exact manufacturer part number: 47-281387.
- Check the permitted axle ratings on the vehicle identification plate wherever a limit is listed.
- Confirm electronic damping, drivetrain and original sports-suspension options against the table.
- Check any additional parts, exclusions and certificate conditions in the application notes.
Installation and adjustment
Follow the installation instructions and approval document supplied for this part number. Keep any adjustable spring seats within the specified range. Have wheel alignment checked after fitting and check affected headlamp or driver-assistance settings in accordance with the vehicle manufacturer’s instructions.
Ordering from GSM Performance
This part is ordered from our supplier. Contact us for the current lead time, particularly if you need it for a planned installation or event. Send your registration or VIN and original suspension details if you would like us to check the application.
Ordered from supplier. Contact GSM Performance for the current lead time.
Will this fit my car?
This listing is for the Renault Clio IV (BH_) built from 11/12 to 06/15. The application table covers the 0.9 TCe, 1.2 and 1.5 dCi engines (54 to 88 kW) and notes the type as ex. RS, so check your car against it before you order. If anything is unclear, send us your registration or VIN and we will check it.
What can I adjust?
The ride height is adjustable on the threaded body, and Bilstein quote a lowering of about 30 to 40 mm at the front and 30 to 40 mm at the rear. The damping is fixed, set by Bilstein for the car.
Is it right for road or track?
It depends how much of your driving is on track. Our guide Fast Road Or Track: Choosing The Damping On A Set Of Coilovers explains what 1-way, 2-way and 3-way adjustment gets you. For the Bilstein range, see Bilstein B12, B14 or B16: Which Suspension Adjustment Do You Need?.
Can I fit it myself?
Our guide Fitting Coilovers At Home Or Having Them Done covers what the job involves. Either way, have the wheel alignment checked after fitting and check wheel and tyre clearance through full steering lock and suspension travel.
How long does it take?
This kit is ordered in from the supplier for your car. Ask us for the current lead time before you book the fitting.
More about this kit.
What lead time is listed for 47-281387?
The catalogue lead time for 47-281387 is: Contact us for current lead time. This is an ordering estimate, not a guaranteed delivery date. Confirm current availability and timing with us before relying on it.
What ride-height information is listed for 47-281387?
For 47-281387, the catalogue gives: “Front: 30-40 mm / Rear: 30-40 mm”. Use any front and rear figures with their listed vehicle and fitting conditions. Ask the installer to check the finished clearances and alignment.
Bilstein suspension: allow 3 to 5 weeks
Allow 3 to 5 weeks from your order for your Bilstein suspension to reach you.
Need it by a particular date? Write the date in the order comments box at checkout when you order.
